Saturday, May 4, 2013

A Little About Encryption

My people have no tradition of proofreading.  —Ken White

This is the third of three posts on encrypting email.  The others are It's Time to Encrypt Your Email and Using Encrypted Email

About Encryption

Encryption mathematically scrambles the bits of your email messages or other documents so that the content is impossible to read without reversing the encryption process.  The encrypting process combines a long and random collection of bits called the key with the message to to produce an encrypted message, called the cipher text.  This is analogous to putting the message in an envelope, except that the envelope cannot be opened without the key.  The cipher text can be safely sent to the recipient electronically; even if the message is intercepted, the adversary will not be able to read it. Decrypting the message involves reversing the process using the same key, as shown in the diagram.  A system of encryption that uses the same key for both encrypting and decrypting is called secret key or or shared key or symmetric key encryption.


You've spotted the problem!  Sender and recipient must each have a copy of the key, so you have to figure out a way to get the key to your recipients securely and hope they keep it secure.  You also have to have a separate key for each person with whom you want to correspond; otherwise, all will be able to decrypt everyone else's messages.  Symmetric key encryption has important uses as we see below, but for correspondence, it doesn't scale well when used by itself.

Public Key Cryptography

In the 1970s, three groups of researchers independently invented a mechanism that uses two different keys with the same message, one to encrypt and one to decrypt.  The key usually used for encrypting is called the public key, and the key usually used for decrypting is called the private key.  Here's what's important:  a message encrypted with one's public key can only be decrypted using the corresponding private key.  You can give the public key to anyone, and they will not be able to decrypt messages that others may have encrypted with the same public key.

You can give your public key to everyone with whom you correspond.  Only you will be able to decrypt the messages they encrypt for you.  In fact, there are public key servers that will allow you to post your own public key and to look up the public keys of others.  One such key server is keys.openpgp.org.  You will probably want to upload your public key to that one or another.  You could try looking up the public keys of others right now by clicking on the link.

Hybrid Cryptography

There's a problem with public key cryptography: it's a lot of computational work.  Encryption using public key cryptography can take as much as 10,000 times longer than encrypting the same message using symmetric key cryptography.  Encrypting a message could take from several minutes to hours.  We probably don't want to wait even a few minutes for the encryption process.

Symmetric (shared) key encryption is much faster, with times in seconds for even very long messages.  But, as we saw earlier, the problem is how to get a copy of that shared key securely to the recipient.  The solution is to use public key cryptography to solve the key exchange problem.  The sender generates a random number that's used to create a key for symmetric key encryption, using something like the Advanced Encryption Standard (AES.)  So, encryption can be completed very quickly.  The symmetric key is called a session key when used this way because each key is used for only one message or communication session.  The session key itself is encrypted using public key cryptography and the recipient's public key.  Because the session key is short – perhaps 256 bits (32 bytes) – the time to encrypt it is minimal.  The encrypted message and encrypted session key are packaged together and transmitted to the recipient.  This two-step process is called hybrid cryptography, and is almost always the way public key cryptography is employed to secure messages from eavesdropping.

The recipient reverses the process.  The session key is first decrypted using the recipient's private key.  Then, the session key is used to decrypt the message.  Besides speeding up the process, use of session keys and hybrid cryptography actually improves the security of messages because it deprives an adversary of the chance to collect many messages encrypted with the same key.  That's important for two reasons: having a large collection of text encrypted with a single key may make the cryptanalyst's job easier, and, if the key for one message is cracked, all the messages are revealed.  (Of course, if the cryptanalyst can recover the recipient's private key, the public key no longer offers security.  But, if the cryptanalyst cracks one session key, the other messages remain secure because they were encrypted with different session keys.)

Idea: A Digital Signature

The two keys of a public key crypto key pair are cryptographic inverses of one another.  A message encrypted with one key of a pair can only be decrypted with the other key of the same pair.  In the normal course of things, Alice would encrypt a message using Bill's public key, and Bill would decrypt it with his private key.  That would keep the message confidential while it travels over an unsecure channel.

If Alice encrypts a message with her private key, Bill or anyone else could decrypt it using Alice's public key.  There's no confidentiality because the message can be decrypted with Alice's public key, and that's, well, public.  However, if we believe that Alice has guarded her private key carefully, only she could have encrypted the message. So, we can say that Alice has digitally signed a message that was encrypted with her private key.

Encrypting a message with a private key (to sign it) has the same problem as encrypting with a public key to secure it, namely that it would take a very long time.  We need a way to characterize a specific message that is shorter than the message itself.

Cryptographic Hashes

In the early days of computing, it was common to add up a series of numbers before entering data into a computer, then add them up again with the computer.  If one got the same total, that was a good indication that the data entry process was free of errors.  Sometimes the numbers were things like birth dates, where a total did not have any meaning other than as a check for consistency.  Such totals were called "hash totals."

The characters that comprise a computer message are just numbers.  In theory, we could add them up to get a hash total that could serve as a consistency check on the message. In practice, it's a little more complicated.

A cryptographic hash function has three special properties.  First, even a tiny change in a message, like adding a zero to make $100 into $1,000, must change the computed hash code.  Second, it should be impossible, given a message, to create another message that produces the same hash code.  There exist hash codes that are thought to meet both criteria.  We can think of the computed hash code as a kind of fingerprint for a message.  Different messages always have different fingerprints, even if the difference in the messages is very small.  A hash code computed over a message is called a message digest.

The third property is that one cannot reconstruct the message given only the message digest.That's important because the digital signature exposes the message digest to an adversary.

The Digital Signature Improved

Given that we can compute a cryptographic hash, we can improve upon our idea of a digital signature.  Instead of encrypting the entire message with her private key to sign it, Alice can compute a cryptographic hash over the message and encrypt the hash code only using her private key.  Since the hash code is short – perhaps 256 bits – it, like a session key, can be encrypted quickly even with public key cryptography.  The encrypted hash code is sent along with the message to serve as the digital signature.

Such a digital signature not only authenticates the sender, it protects the message from tampering while in transit.  Here's why: Anyone can decrypt the digital signature using Alice's public key, but only Alice could have encrypted it.  Bill can verify the message by computing the hash code anew, then comparing it with the decrypted hash code sent with the message.  If they're equal, we can be sure the message actually came from Alice.  We can also be sure the message hasn't been altered.  If Evil Eve had altered the message, the hash code Bill computed would  be different from the one Alice computed.  The computed hash code wouldn't match the decrypted hash code, and the digital signature validation would fail.  (Eve can't replace the hash code after altering the message because doing so requires Alice's private key, which only Alice has.)

Putting the Pieces Together

We can encrypt a message using hybrid cryptography, and we can authenticate it using a digital signature.  If we put those pieces together, we can package a message that only the intended recipient can decrypt, and for which the authenticity of the sender is assured.

The diagram below shows what happens when Alice's encryption software prepares a digitally-signed and encrypted message for transmission to Bill.  Plain text (unencrypted) information is represented by green boxes, encrypted information by red boxes, and keys by orange boxes.  The package of information that is transmitted to Bill is surrounded by a blue box.  The digital signature is "sort of green" because, although it is encrypted, anyone can decrypt it using Alice's public key.The circle-plus symbol indicates encryption.


Alice's encryption program uses a cryptographic hash algorithm to compute a message digest of the plaintext message, then encrypts the message digest using Alice's private key to form the digital signature.  A random number generator is used to produce a session key.  The session key will be used only once, for this message.

The plaintext message is encrypted using the session key and a symmetric key encryption algorithm such as AES.  The session key itself is encrypted with Bill's public key.

There are three encryption operations.  Symmetric key encryption is used for the "main" message because it is comparatively fast.  Public key encryption is used to produce the encrypted session key and the digital signature.  This works because, although public key encryption is slow, both the message digest and the session key are small, perhaps 32 bytes each.  The "package" sent to Bill includes the three main components shown in the diagram and some additional information.  It identifies Alice as the sender, Bill as the recipient, and names the encryption algorithms used.  It is possible to include more than one encrypted session key.  If Alice wanted to send the same message to both Bill and Charlie, the package would include a copy of the session key encrypted with Bill's public key and another copy encrypted with Charlie's public key.

Bill Receives the Message

Bill gets the packaged message over the Internet by email, or perhaps in some other way. The session key was encrypted by Alice using Bill's public key.  Using Bill's private key, Bill's crypto program decrypts the session key.  The session key is used to decrypt the actual contents of the message.  Since only Bill has a copy of his private key, only Bill can decrypt the session key, and hence decrypt the message.  The message is now available in plaintext.  The next step is to check that it really came from Alice and is not a forgery.

Alice digitally signed the message by encrypting a message digest using her private key.  We know two things about that.  Since the digest was encrypted with Alice's private key, only Alice's public key can decrypt it.  Since only Alice has a copy of her private key, only Alice could have encrypted it.

Bill uses Alice's public key to decrypt the digest that is the digital signature.  Bill also computes a new message digest from the plaintext message.  The decrypted digest and the computed digest are compared.  If they are equal, Bill has confidence that the message actually came from Alice, and also that it hasn't been tampered with.  If they're not equal, then something is wrong and Bill must mistrust the message.

The amount of confidence Bill has in the authenticity of the message depends on the amount of confidence Bill has that Alice has kept her private key secure.  If Bill is sure that Alice has kept her private key secure, then Bill can be sure the message came from Alice.  If malicious Mallory has gotten a copy of Alice's private key, then Mallory could have forged the message.

Notice that if Eve the eavesdropper can intercept a copy of the message, Eve can decrypt the digital signature with Alice's public key because it is, well, public.  However, it doesn't do Eve any good because one of the characteristics of that cryptographic hash is that the message cannot be reconstructed from the message digest.

Digital Certificates

In a previous post, I wrote about signing others' public keys as a way to improve our confidence that the key actually belongs to the person it claims to belong to. We saw earlier how a message could be both authenticated and protected from tampering through the use of a digital signature.  A public key can be protected in the same way.  When a public key is digitally signed, the result is called a digital certificate

The purpose of a digital certificate is to bind an identity to a public key.  When you created your public/private key pair, you put in your own email address, but you could have claimed to be alice@example.com or even president@whitehouse.gov.  If you could get someone to use such a public key, thinking they were corresponding with the real Alice (or President) you'd be able to decrypt the messages because you have the corresponding private key.  A digital certificate helps us increase our confidence that a particular public key actually belongs to the claimed party.  It binds an identity to a public key.
The diagram at the left is a simplified representation of a digital certificate.  The part in green is all plain text.  It identifies alice@example.com as being the owner of the given public key.  This certificate has two digital signatures, one by Bob and one by Charlie.  By signing this certificate, Bob and Charlie are certifying that they have checked that the given public key actually belongs to alice@example.com.

Here's how it works.  The certificate is just a message consisting of an identifier, a public key, and other information in plain text, the part shown as green in the diagram.  Each signature has two parts, identification of the signer, shown in yellow-green and stored as plain text, and an encrypted hash code, shown in red and encrypted with Bob's private key.  Someone who knows and trusts Bob can compute the hash code directly, using the part of the certificate shown in green, then use Bob's public key to decrypt the part shown in red under Bob's identifier.  If the computed hash code and the decrypted hash code match, we can have confidence that the part of the certificate in green hasn't been tampered with, and that the public key given really does belong to Alice.  How much confidence we have depends upon how much we trust Bob.  If we don't know or trust Bob, perhaps we know Charlie or someone else who has signed Alice's key.  The subject of trust was discussed in Using Encrypted Email.

A digital certificate can be signed by a number of individuals, creating a web of trust, or by a single trusted organization, called a certificate authority.  OpenPGP uses the web of trust model.

A Note on the Strength of Cryptography

Modern cryptosystems are very difficult to break, but probably not impossible to break.  If you used a 4,096-bit key size when you generated your key pair, cracking your encryption would take dozens of years using the best algorithms and fastest computers available.  Of course, Moore's law means that computers are getting faster, and in a dozen years, 4,096 bits may not be enough.  For now, even with a 2,048 bit key size, you are probably safe from any person or agency except possibly the NSA.

The weak points are the private key, stored on your computer and the passphrase, stored in your head. If an adversary can get both of those, your privacy is toast.  Without them, your privacy is protected against casual snoopers, and even persistent snoops like reporters.  You are in more danger from something like this than you are from a computational attack. Your private key backup is another weak point.  Guard it carefully.


While we're talking about the strength of cryptography it's time for a warning: don't roll your own.  While it might seem very cool to design and implement your own cryptosystem, it turns out to be surprisingly hard to do right.  Unless you have the equivalent of a Ph.D. in mathematics with an emphasis on cryptology, it's an extremely bad idea to trust important information to home brewed crypto.  Experiment all you want, but when you're serious about protecting information, use cryptosystems developed by experts, examined by other experts, and that have withstood the test of time.

Cryptography and the Law

There's a different question when it comes to law enforcement: can you be compelled to decrypt documents?  Even if law enforcement agencies cannot crack your encryption, they may be able to get a court to order you to decrypt documents yourself or to surrender your passphrase.  If you refuse, you might be held in jail until you change your mind.  Whether the Fifth Amendment protection against self-incrimination means you do not have to reveal your passphrase or the contents of encrypted documents has not been settled as of summer, 2013.  Different courts have ruled differently.  There is also a distinction at law between being forced to divulge your passphrase and being forced to produce documents in plain text (decrypted) form.

I'm not a lawyer, and cannot give legal advice.  Good, common sense advice is not to do illegal things nor possess illegal materials.  Encryption may delay an investigation, but it is unlikely to save you from the consequences of illegal actions.

With that said, I cannot emphasize too strongly that, in the United States, there is nothing illegal about using encryption.


Previous article: Using Encrypted Email

Copyright © 2013 by Bob Brown
Last updated: 2021-03-14

Creative Commons License
A Little About Encryption by Bob Brown is licensed under a Creative Commons Attribution-ShareAlike 3.0 Unported License.

Some of the symbols used in some of the illustrations were borrowed from a document on the subject of public key cryptography by Microsoft. Thanks, Microsoft!  The XKCD cartoons are used under the terms of the Creative Commons Attribution-NonCommercial 2.5 License.The quotation by Ken White is used by permission.


Using Encrypted Email

My people have no tradition of proofreading.  —Ken White

This is the second of three posts on encrypting email.  The others are It's Time to Encrypt Your Email and A Little About Encryption
If you've followed the directions in "It's Time to Encrypt Your Email," you have an email client that's set up to encrypt messages you send and decrypt messages you receive.  Now what?

Someone To Write To

Being the first person on your block to have public key cryptography for your email leaves you with no one with whom you can correspond securely. Let your frequent correspondents know about these articles and help them get started with public key cryptography for their email.  If you recruit two people to use encryption and each of them also recruits two more, soon everyone will be doing what we should be doing.

The Subject May Not Be Encrypted

If you're using Thunderbird version 78 or higher, the subject lines of your messages will be encrypted.  Other encryption mechanisms may not encrypt the subject.  This means that anyone who can eavesdrop on your mail stream can read your subject lines.  If your main reason for encryption is to foil casual snooping, just use subject lines as usual, but be aware that you are potentially revealing information. Alternatively, you can use uninformative subjects like, "Encrypted message."  (An eavesdropper will be able to tell which messages are encrypted anyway, so you haven't revealed anything.)  For voluminous correspondence, where subject lines might be needed to categorize messages, and should not reveal information to eavesdroppers, you could use a code.  A subject of, "Spending weekend with Grandpa" might indicate one type of message, and "What about pizza?" another.

Or, you could use Thunderbird, which encrypts the subject line.

Traffic Analysis

An adversary who can eavesdrop on your email can see with whom you correspond even if the contents of the messages remain hidden.  Sometimes inferences can be drawn from that information.  For example, if the owner of a successful private company suddenly starts communicating with investment bankers, one could speculate that the company is about to go public.  Traffic analysis countermeasures are far beyond the scope of this article, but users of encryption should be aware of the possibility that "they" know to whom you are writing, even though they can't read the messages.

It is increasingly the case that email systems use TLS/SSL encryption between client and server, and from one email server to another.  Although that makes traffic analysis more difficult, he header information of email messages is necessarily unencrypted while the message is "at rest," either on a server or at the origin or destination.  An adversary with access to an email provider's servers can read all of the header information: sender, recipients, and the rest, and possibly subjects.  Some adversaries, like governments, might be able to compel access to email providers' servers. Of course, if the adversary can install monitoring software on the computer at the origin or destination, no part of the message is secure, even if the body is encrypted.

Digital Certificates

If Evil Eve the Eavesdropper could somehow replace Alice's public key with Eve's own, then Eve would be able to read messages intended for Alice.  We guard against that by embedding public keys in digital certificates.  A self-signed digital certificate is a digest (electronic fingerprint) of the public key and identifying data, computed using a cryptographic hash function and encrypted with the owner's private key.  Because public and private keys are cryptographic inverses of one another, anyone can compute the digest of Alice's digital certificate, then use Alice's public key (from the certificate) to decrypt the digest from the certificate, and finally compare the two.  In theory, if the two digests match, one should be able to trust the public key.  In practice, a self-signed digital certificate provides no significant protection against replacing both the public key and the encrypted fingerprint.  Self-signing does protect the certificate from tampering.

We overcome the problem that Eve could have generated a completely forged certificate by having the digital certificate signed with the private keys of one or more trusted third parties.  One approach is to use a single trusted party, the certificate authority.  The other approach, and the one employed by OpenPGP, is to have that key fingerprint signed by several third parties in whom we place varying degrees of trust. (Note: As of spring, 2021, the Hagrid keyserver at keys.openpgp.org does not support key signing.)

A third party signs a certificate by computing the digest of the identifier and public key, then encrypting it with the signer's private key.  The signer's identity is added to the signature.   Anyone can find the signer's public key and check the digital signature as described above.

There is more about digests in A Little About Encryption.

 Key Signing

If a third party whom we trust has signed Alice's key, we can have a great deal of confidence that we really have Alice's key and not Eve's because changing the key would invalidate the signature.  If we don't know the person who signed Alice's key, we have a lot less trust.  Perhaps Eve has subverted the signer.

If several people have signed Alice's key, our confidence increases because Eve the Eavesdropper would have had to subvert each of them.  The more signers, the more confidence we can have, especially if one of the signers is known to us.  This creates the "web of trust" that lets us have confidence that the public keys of others have not been tampered with, and does so without the need for a central authority.

You may be asked to "sign" someone's key, or you may want to ask someone to sign yours.  To have a friend sign your key, approach the friend in person, with your name or email address and key fingerprint written on paper.  If your friend agrees to sign your key,your friend will take the paper, obtain your public key from a key server, and verify that the key fingerprint you supplied on paper patches that of the key from the key server.  If the two fingerprints match, your friend will get your key from a key server, "certify" the key as belonging to you by adding his digital signature, and send it back to the key server.

There's no need to go wild, but your key will be more trusted if at least four or five people have signed it; more is better. Try to have it signed by people who move in different circles; that will increase the probability the someone who needs your key will know someone who has signed it, or "know someone who knows someone."

A Key Signing Party

 Since getting people who can verify each others' identity to sign each others' public keys is a Good Thing, and since socializing with like-minded people is also a Good Thing, you might want to host (or instigate) a key signing party.  You won't even need access to computers at the party.  The host prepares a list of attendees and information about their public keys and makes a copy for everyone at the party.  Attendees bring their own key information and picture IDs to the party.  Each guest checks the information for each other guest, and then later signs the keys of those whose information checks out.  The "later" part is why you do not need, and should not have, computers at the party.

There are many sets of instructions for organizing key signing parties on the web.  The best one I've found so far is the W4KWH Key Signing Party Guide.

If you host or attend a key signing party, be sure you scrupulously verify the identification and key information of everyone whose key you intend to sign.  Do not make this mistake:











Trusting Others' Certifications

Suppose Alice wants to communicate securely with Bob. She retrieves Bob's public key from a key server and  finds that it has been signed by Charles, David, Frank, and George.  Can we say more about how certain Alice can be that she really has Bob's public key than, "signed by four people?"  Yes, especially if Alice knows any of those people, or knows anyone who has signed their keys..

Alice (and you) can assign a level of trust to every key on her keyring of public keys.  This is a subjective decision; Alice (and you) get to decide.  The levels of trust are:
  1. Unknown
  2. Untrusted (known to sign public keys carelessly or maliciously; see the cartoon!)
  3. Marginally trusted (probably careful when signing public keys)
  4. Fully trusted.
Anything signed with Alice's own private key is assumed to be fully trusted; everything else is initially set to "unknown."  Alice can change the trust level of keys on her keyring.  If Charles's key is on Alice's keyring, she can set its trust to "marginally trusted" or even "fully trusted."

Given the idea of levels of trust, one can apply an algorithm to help Alice decide whether the key she has retrieved from a key server for Bob is really his.  A key is valid (i.e. trustworthy) if two conditions hold.  First, it must have been signed by "enough" trusted keys.  "Enough" means:
  1. Alice has signed it herself, or
  2. It has been signed with at least one key that is fully trusted by Alice, or
  3. It has been signed with at least three keys marginally trusted by Alice.
The second condition is that the path of signatures from Bob's key to Alice's has five or fewer steps.  That may seem very restrictive until one considers the concept of six degrees of separation.

Those are the default parameters for GnuPG; you can change the parameters to be more or less restrictive.  Levels of trust are private, and are not shared or exported when you sign someone else's public key.

Creating a Revocation Certificate

Once a key has been uploaded to a key server, it is effectively impossible to remove.  Yet, you might want to remove your key for a number of reasons.  It might be something as scary as having your private key compromised, or as mundane as getting a new email address, which is effectively a new identity.  (You can also deal with a new email address using subkeys, which are explained in the Gnu Privacy Handbook.  Subkeys are really the right way to deal with new addresses.) Although you can't remove a key from the key servers, you can revoke it... if you have a revocation certificate. Revoking your key tells everyone it is no longer effective to use that public key.

The revocation certificate must be signed using your private key.  One of the reasons you might want to revoke a public key is that you no longer have access to the corresponding private key.  As I wrote in an earlier post, that can happen if you forget your passphrase or have a disk failure.  So, generate that revocation certificate soon after you generate your key pair.  Once you've generated a revocation certificate, do not import it.  You will do that only if you're ready to revoke the public key.  Instead, store it someplace safe.  Remember, anyone who can get access to your revocation certificate can revoke your public key.

You will need to use the command interface of GnuPG to create your revocation certificate.  Open a command window and navigate to the directory where gpg.exe is stored.  On my computer, that's
\Program Files\GNU\GnuPG.
The command line to enter is
gpg --output <key ID>.revoke.asc --gen-revoke <key ID>
Where <key ID> represents the eight hex character ID of the key for which you want to create a revocation certificate.  Here, edited slightly, is what it looked like when I created a revocation certificate for key ID 375F8696.  What I typed is in bold.

gpg --output 375f8696.revoke.asc --gen-revoke 375f8696
sec  2048R/375F8696 2013-04-07 Bob Brown <my_email>
Create a revocation certificate for this key? (y/N) y
Please select the reason for the revocation:
  0 = No reason specified
  1 = Key has been compromised
  2 = Key is superseded
  3 = Key is no longer used
  Q = Cancel
  (Probably you want to select 1 here)
  Your decision? 1
  Enter an optional description; end with empty line:
  >
  Reason for revocation: Key has been compromised
  (No description given)
  Is this okay? (y/N) y
You need a passphrase to unlock the secret key for
  user: "Bob Brown <my_email>"
  passphrase entered here
  2048-bit RSA key, ID 375F8696, created 2013-04-07
  ASCII armored output forced.
  Revocation certificate created.

The result will be a file called <key ID>.revoke.asc; in the example, 375F8696.revoke.asc, in the same directory where you ran the command.  Do not leave it there!  You need the revocation certificate if you lose access to your private key, which could happen if your computer is stolen or your hard disk fails.

These instructions came from the Gnu Privacy Handbook.  I recommend having a good look at it to see what else one can do with

Signing Unencrypted Messages

GnuPG can be used to add a digital signature even to messages that haven't been encrypted.  Such a digital signature makes the messages tamper-evident and provides for cryptographic authentication of the sender.  It also adds PGP headers and a base 64 encoded digital signature to the body of the message, making one's messages somewhat ugly.  There are two reasons for signing unencrypted messages.  One, of course is to provide tamper-resistent, authenticated messages.  The other, and possibly the more important one, is for it to cause recipients of such messages to say, "WTF?" and thereby open a discussion of why they, too, should be encrypting their email.  For that second reason alone, it may be worth it.

Validating (Verifying) Signed Messages

Mail clients like Thunderbird can be configured to add digital signatures to all messages by default, even those that are not encrypted.  Some can also be configured on a per-address basis.  Consider adding a digital signature to all of your email, or at least to mail sent to friends who might be amenable to encrypting their own email.

The cartoon is a little tongue-in-cheek... well, a lot tongue in cheek.  Validation of signatures is automagic if the recipient is using an email client that understands OpenPGP.  Such a client may even conceal the headers and just give a green bar or other indication that the message has been authenticated.  Someone using an email client that doesn't understand OpenPGP can still validate digital signatures.  To do so, copy the entire message, beginning with "-----BEGIN PGP SIGNED MESSAGE-----" and ending with "-----END PGP SIGNATURE-----" and save it to a temporary file.  It can then be validated using the Decrypt/Verify File function of Kleopatra.  (It's under the File menu.)  The recipient must have imported the sender's public key certificate.

Thunderbird Portable Edition

My laptop goes where I go, so I can deal with encrypted email just about anywhere.  If you primarily use a desktop computer and set up encryption there, it might be difficult to read or send encrypted email from elsewhere.  One solution might be Thunderbird Portable Edition.  This is Thunderbird bundled with the PortableApps launcher so that it will run from a USB flash drive. Using Thunderbird this way leaves no information behind on the host computer.  The Windows operating system is required.

If you set up and use Thunderbird Portable Edition, your private key will be on that flash drive; be sure to guard it well.  Consider using an encrypted flash drive.

If you use any of the PortableApps applications, please consider making a donation or buying one of their flash drives.  The software is free; the effort of making it portable is supported by donations.


Previous article: It's Time to Encrypt Your Email    Next article:A Little About Encryption

Copyright © 2013 by Bob Brown
Last update: 2021-02-22

Creative Commons License
Using Encrypted Email by Bob Brown is licensed under a Creative Commons Attribution-ShareAlike 3.0 Unported License.

The XKCD cartoons are used under the terms of the Creative Commons Attribution-NonCommercial 2.5 License.The quotation by Ken White is used by permission.

Thursday, May 2, 2013

It's Time to Encrypt Your Email

My people have no tradition of proofreading.  —Ken White

Too long; didn't read

I set out to write some simple instructions on setting up encrypted email.   Being a college teacher, I couldn't resist answering the "because" question for every step.  I also wandered into the ways one could use encrypted email and the other features available.  The article became way too long for anyone to actually use, so  I've broken it up into three parts.  This is the first of the three.  The other two are:

This article has been extensively revised because the Thunderbird email client now supports native encryption. (Note added 2021-02-21)

Why Encrypt?

We've read about "hackers" and reporters breaking into peoples' email. The FBI is back again with a proposal that would make "wiretapping" electronic communications easier. It's probably already too easy. If you're not sure, ask David Petraeus. Current (2013) law provides very little protection for email messages and almost none for messages left on your mail provider's server for longer than 180 days.  According to the Electronic Frontier Foundation, some of the biggest providers of email (Apple, AT&T, Comcast, Verizon, and Yahoo) do not require warrants for access to "content," which appears to include email.  (2019 data.)  In the summer of 2013, we found that snooping by the NSA in particular is far more widespread than most of us had imagined.

Most of the personal email most of us write is completely innocent, things like deciding on where to go for pizza, but even innocent email can contain confidential information.  I needed the Social Security numbers of my nieces and nephew to make them beneficiaries in case of my death.  Even though those exchanges were innocent, they contained information others should not have. I have recently been reminded that anything you communicate to your lawyer should be encrypted to protect the attorney-client privilege.

As you can see, there are good reasons for keeping your email confidential.  The best one is that the contents of your email are none of their damn' business!  whoever "they" may be. You can protect your personal email by encrypting it, and it's easy to do.  Read on to find one way to do it.

Following these instructions will allow you to encrypt mail that you want encrypted, and all the software you need is free.  Messages that you don't want encrypted will not be.  That's important because many of the people with whom you correspond will not have encryption set up at "their end."   Tell the ones who don't about this article!

Two Ways to Encrypt Email

Email can be encrypted using one of two standards, S/MIME or OpenPGP, that are not interoperable.  The Thunderbird email client discussed below is ready for either standard out of the box.  The trouble is, S/MIME requires a digital certificate for which you might have to pay.  These instructions are for OpenPGP, which is based on a "web of trust" rather than on digital certificates.  (If you have friends who use S/MIME encryption, Comodo offers free certificates with a one-year expiration period.  You can install both S/MIME and OpenPGP encryption, but you have to keep track of who uses what.)

Note for Users of  MacOS

The instructions below will work for MacOS, but after I wrote this, the folks who develop GPG Tools for Mac released Version 2 of GPG Mail.  I don't have access to a Mac, so I haven't tested this personally, but a colleague with a Mac says it just snaps in and works.  If you use the Apple Mail application, you can probably just install GPG Mail instead of following my outline.  Before you start, please do read about pass phrases, key generation, and making a backup of your private key, below; that information is applicable to configuring GPG Mail.  You should actually read the whole article, and the two that follow.  If you try using GPG Mail, please leave a comment reporting your experience.  (Note added 2013-08-11.)

What We are Going to Do

These instructions are primarily for Windows users, but the software described will run on Linux and Mac OS as well.  This may seem long and complicated, but if you take it step-by-step, it'll be easy.  I recommend reading through the entire post before you start.  Here's what we're going to do:
  1. Install a "local" email client, Mozilla Thunderbird, on your computer.  You may already be using Thunderbird.
  2. Devise a passphrase to protect your private key.
  3. Generate your own public/private key pair.
  4. Enable OpenPGP encryption in Thunderbird.
  5. Upload your public key to a keyserver.
  6. Make a backup of your private key.
Optionally, you may want to create a revocation certificate and have your public key signed by a few other people.  There's more on that in Using Encrypted Email(Note: As of spring, 2021, the keyserver at keys.openpgp.org does not support key signing.)

Install a Local Email Client

To start with, you will need an email client that runs on your own computer.  If you are already running Thunderbird, be sure you're running version 78 or higher and you're done with this step.

Otherwise, download and install Mozilla Thunderbird.  In most cases, Thunderbird can configure itself automatically with just your email address because it has a database of settings for major email providers.  If, for some reason, automatic configuration fails, you will need, from your email provider, the server addresses and port numbers to configure IMAP or POP incoming mail and SMTP outgoing mail.  These should be available from your email provider's support site.  You will also need to know the connection type, which will often be SSL/TLS.

 If you use Thunderbird, to keep your private key secure, you must set a master password.  Use a pass phrase, not a word, as described in the next section.

Devise a Passphrase

It is important that you keep your private key private.  You will use a "password" for that.  Your encryption is no stronger than this word or phrase. Please don't use any of the top 10,000 passwords.  I recommend using a phrase you will remember, something like, "My best times are those I spend at the beach."  That is very easy to remember, but it would be difficult even for someone who knows me well to guess it exactly.  The phrase should be more than a couple of dozen letters to foil automatic guessing, but you may have to type this phrase every time you encrypt or decrypt a message, so don't write a book!


The people who write password cracking software are onto the rules of grammar.  For a little more strength, you might rephrase as Yoda-speak: "Those I spend at the beach my best times are," or change the grammar around in another way.

For the strongest passphrase, generate it with Diceware.  You can also read the original Diceware article.  Use real dice or the dice from random.org. Throw five dice per throw and use the Electronic Frontier Foundation's long word list.

If you forget your passphrase, you're toast.  Write it on a slip of paper and put it in a book you use infrequently. When (if ever) you are absolutely sure you have it memorized, tear that slip of paper into tiny pieces and flush them.

Generate a Key Pair

Once you've settled on a passphrase, you are ready to generate your public and private keys. From the "hamburger menu" at the top left, choose Account Settings > select your account > End-to-End Encryption > Add Key.  The default size of 3,072 bits is probably enough.  For extra strength, choose 4,096 bits.  I made my key unexpiring.  For highest security, expire the key at intervals.

Upload Your Public Key to a Keyserver

To make your public key as public as possible, upload it to a keyserver.  The keyservers talk to each other, so uploading to one of them is generally enough. Thunderbird is configured to use https://keys.openpgp.org/ as its keyserver. It isn't (yet) clear to me whether your public key is uploaded automagically.  About an hour after you've configured encryption, go to the keyserver using the link above and search using your email address.  If it finds you, you're done.

If not, do the following: Within Thunderbird's End-To-End Encryption panel, click "OpenPGP Key Manager."  In the  Key Manager, select your key and choose File > Export Public Key(s) to File.  Save the exported file and in a web browser, navigate to keys.openpgp.org.  Choose the upload link from the main page, browse to your file, and upload it.  Click Send Verification Email.

Make a Backup of Your Private Key

Earlier I wrote that if you forget your passphrase, you're toast.  The same thing is true if you lose your private key.  If you've followed these instructions, your private key is stored on your computer in Thunderbird's profile directory.  A disk crash or a new computer might mean you can no longer decrypt mail that others send to you.  To prevent that, make a backup of your private key now and any time you make a change.

To do that, within Thunderbird's End-To-End Encryption panel, click "OpenPGP Key Manager."  In the  Key Manager, select your key and choose File > Backup Secret Key(s) to File. You will need to set a password.  If you forget the password, you're toast.  If someone else gets a copy of the file and guesses the password, you're toast.  Copy the backup to a flash drive, preferably encrypted, or burn it to CD and guard it carefully.  Maybe make more than one copy.  I have a copy in the safe deposit box at my bank.

Exporting your private key also exports your public key.  If you ever need the backup, you will be able to import it.

What About Web Mail, Tablets, Smart Phones?

To be secure, encryption and decryption necessarily has to take place on the "end device," your computer, tablet, or phone.  If it happened at your email provider's server, your email provider would have to have your key.  If they have your key, they can divulge the contents of your email, perhaps accidentally or perhaps under a secret court order.

If you were using a web mail client, it will still work, but you won't be able to send or read encrypted mail. The post on Using Encrypted Email includes a brief discussion of Thunderbird Portable Edition, which will let you use encryption with others' computers.

For phones and tablets, there is software for Android that will let you use encryption, and software for iOS that will allow reading, but not creating, encrypted messages. A new iOS app seems to provide full encryption and decryption.  I've successfully installed APG and K-9 on my Android tablet and can send and receive encrypted mail.  I'll try to write some instructions presently.  (Didn't happen.)

About Your Work Email

Even if you work for a very permissive organization, they probably wouldn't appreciate your adding encryption to your work email.  Beyond that, free email accounts are readily available for personal use. I finally subscribed to a paid email service for my personal email on the basis that "free" is often worth the price charged. Mixing personal and work email can cause you serious problems.  For some examples, search on "fired because of email" for stories like this one.

Some Terminology

These definitions may help you navigate the documentation of the programs with which you will be working.
OpenPGP
OpenPGP is a standard describing a mechanism for both encrypting and digitally signing files. Those files may be email messages or a "plain" data file. There is no "OpenPGP" program; two programs that implement the OpenPGP standard are described below.
PGP
PGP was a company, since acquired by Symantec, and also the name of that company's products. The PGP products implement the OpenPGP standard. They're commercial products; they cost money. People pay Symantec money to get technical support, regular product upgrades, etc. If you are installing encryption for a company, and not for personal use, consider the Symantec products or those offered by other companies.  There was a free version of PGP, but it is now very out of date and should not be used.
GnuPG
GnuPG, also called Gnu Privacy Guard or GPG, is a free and open-source implementation of OpenPGP. As with other free software, support consists only of forums, mailing lists, and web articles. Upgrades and fixes are contributed by a dedicated group of volunteers.
Certificate
GnuPG refers to your public key and those of others as certificates because that's what they are. What's produced is a public key with a digital signature signed with the corresponding private key. That's a self-signed digital certificate. While it doesn't provide any assurance of correct binding to an identity, it does provide protection against tampering.

Ready for More Information?

Now that you have encryption set up, read Using Encrypted Email.  For an overview of how this all works, try A Little About Encryption.

Did You Do This?

Every encrypted message is a tiny protest against the government's massive surveillance apparatus.  Please encourage others by leaving a comment below.  It can be as short as "I did it!" or as long as a description of your experience, but you really will help others.  Please spread the word by sharing this post.  Linking is easiest and lets me make updates, but the Creative Commons license lets you copy the entire post, too.

Copyright © 2013 by Bob Brown
Last update: 2021-03-14
 Creative Commons License
It's Time to Encrypt Your Email by Bob Brown is licensed under a Creative Commons Attribution-ShareAlike 3.0 Unported License.

The quotation by Ken White is used by permission.
